NTS old and new: Progress

In the old days, which I mean before I operated remotely, the common practice was to move a lot of traffic off the net frequency. NCS would direct stations down 3 or 4, or up 3 or 4 KHz, where the action actually took place. This largely still happens, but tonight, I was statled when the NCS sent me down 1 to pass some traffic. I briefly wondered if I’d copied it right. 1Khz? That would seem too close, and certainly would have been back younder, when receivers were wider. They are much tighter today, as I appreciated, after I moved to the newly directed frequency. Since I was using W8KF, he has the automatic mode set so that QSY anywhere automatically sets the mode for the appropriate sideband for the frequency, but I mainly operate CW, so it was necessary to press a few more keys to get back into the internal keyboard, because W8KF doesn’t have the serial interace installed on the server end. After this, I needed to change the mode several times in order to back into CW mode again. I was able to pass traffic even though I was only 1 KHz away from the net, and neither station suffered for the proximity. This was an incredible discovery to make!

Quicker CW

Server owners can arrange the order of the modes any way they want.
This isn’t a problem for accessibility, but it can sometimes mean that you may have to hit control m several times before you’ll find that you have got the rig into CW mode.

Also important, even if you know how far around the wheel the CW position is, you can’t press control m in rapid succession to get there, because you must pause briefly, following each press of control m in order to give the rig time to adjust to the new mode being now currently selected.

Therefore, I have found a quicker way to get the rig functioning in the CW mode, that takes less time than all that extra army strategy of hurry up and wait, hi hi.

So here is how I do it.

This stragegy seems to work reliably on all the remotes I use, and more importantly, it doesn’t matter whether the remote has the serial keying interface which both of the Handiham club stations enjoy.

1. Control f and listen for RC Forab to prompt for the new frequency.
2. Enter the new frequency on the numbers row of the keyboard. Note, pay attention to whether the entry should be in Kilohertz or Megahertz, because this does matter, where you are going.
3. Press enter.
4. Press alt shift f and listen for RC Forb to verify that you’re where you believe you should be.
5. Press tab once.
6. Press alt w, then c, twice. The first time you press c, RC Forb should respond with number. The second time you press alt w, c, RC Forb should respond with Edit.
This means you are now in the box for sending.
7. Press a letter, I generally prefer e because as all CW ops know, E is the shortest letter, and therefore, is the least disruptive.
You’ll hear the rig switch to CW.

6.

Handiham CW Net Session4

We held the 4th weekly session of the Handiham CW net on Friday August 19 at 4 pm CDT.

The club station W0ZSW was used remotely from New Zealand, and the performance was great!

Besides WD8LDY/0/NCS, the only other QNI was VE5SDH, though conditions were poor for propagation.

Afterward, a message was formatted for NTS and sent via NTS to VE7KI.

Attempts to locate a sub NCS for running the 2 Septmeber session has not yielded any firm commitment, although Lucinda AB8WF did indicate that she could pick it up if no one else was found.

KE5AL was asked, as was VE5SDH, but Jim was unsure he could make it, and also concerns were mentioned about coverage from his Texas, which were also raised by Summer from Saskatchewan.

Handiham CW Net review

We’ve now had 3 weekly seesions of the renewed Handiham CW net. Briefly, it meets on Fridays at 4 pm CDT on 7112.

We have had a low QNI count, but progress has happened because we’re up to 2 QNI per the last two sessions. Thanks to Summer VE5SDH for joining me, despite some bad QRN. Hope more will join us for a chat next Friday.

Remotehams User’s Manual for Blind Hams

Remotehams User’s Manual for Blind Hams

By: Dr. Ronald E. Milliman, K8HSY
(1st edition, ©2015-2016)

Acknowledgements

I am hereby expressing my sincere appreciation for the contributions made to this manual by Dave Allen (WD8LDY) who was a tremendous help in reviewing the manual and making very constructive recommendations. In like manner, Lyle Koehler (K0LR) also reviewed the manual and made numerous excellent recommendations for improvements.

Getting Started Using the Remotehams RCForb Client

To date, the use of the Remotehams client is totally free. It is also usable by blind users; though, it could definitely be improved in this regard. The Remotehams website is actually quite accessible, but in contrast, the client software leaves much to be desired in terms of accessibility and blind user friendliness; though, it is usable.

What you can do: you can access numerous remotely controlled stations. You can listen and tune around. You can transmit only if you request and obtain permission from the station’s owner. You can change frequencies, bands, and modes. You can even transmit using CW on those stations set-up for CW operation. With speech enabled as described later in this Manual, you can hear exactly what mode the rig is in, what frequency, and thus, what band the rig is on. So, all of this is good. However, there are lots of things you cannot do as a screen reader user. You cannot adjust any of the slider controls or change the CW speed or adjust many of the other knobs, and controls that are adjustable by our fellow sighted hams. Perhaps we will come closer to more total accessibility over time, especially with more assertive encouragement by some of our vested interest organizations such as Handihams, ACB Radio Amateurs, and the National Federation of the Blind Amateur Radio Division.

To get started, it is highly recommended that you register with Remotehams. This is very easy to do. Go to the Remotehams’ website’s home page: http://www.remotehams.com and tab to the “sign up” link and hit enter on that link. It asks for the usual basic information, e.g. your email address, user’s ID, password, etc. It is strongly recommended that you use your callsign for your user’s ID. Then, shortly after you complete and submit your registration, you will receive a confirmation by email. You will need to follow the instructions in this confirmation to actually activate your account. Once you are registered, and have activated your account, you will have full access to the site.

Then, you need to download the RCForb client software by going to the “downloads” link. There you can download the most recent version of the client software. Like other similar downloads, you will have the option to either download it to your computer and install it, or you can run the .exe file without actually downloading the RCForb program to your computer. Just follow the prompts. When it is installed, you should have a shortcut icon on your desk top which you can click on to start the program.

It is highly suggested that you start by reviewing the keyboard commands given below before you try to access any stations. Otherwise, you will find your initial experience quite frustrating trying to figure out how to control the remote transceiver, e.g. changing frequencies, modes, etc. Also, you should always, without exception, check to make sure someone else isn’t already using the Remotehams station you are logging onto before you do anything else, before you change the frequency, mode or anything. If you don’t check to be certain someone else isn’t already using the station you just logged onto, and you switch frequencies or modes, you could be messing up someone’s qso, and that is definitely not at all the best way of gaining friends in ham radio, and it is my understanding that you could even be barred from logging onto such stations if the station owner receives complaints about your rude and inappropriate behavior when using the RemoteHams service. To check to see if it is okay to tune the transceiver you are logged onto using Remotehams, you can ask if it is okay if you tune if you are not the only person logged into the system. You can determine how many people are logged onto the station if you are using the JAWS screen reading program by switching to your JAWS cursor and arrowing down to where it says: “Users:” and it will show 1, 2, 3, or ever how many are logged onto that station. If the number is 1, then, you know the one person must be you, and you are free to change frequencies, switch modes, etc. However, if there is someone else logged onto the station besides you, you should ask permission to tune the rig either by clicking on the “ask to tune” button or using the keyboard command: ALT-SHIFT A.

Now, here are the other basic keyboard commands you need to be familiar within order to control and interact the Remotehams stations:

ALT-SHIFT-A Ask to Tune

ALT-SHIFT-M Tells you what mode the transceiver is in

CRTL-M Cycles through modes

CRTL-F Set cursor to frequency input textbox

ALT-SHIFT-F will give you audible frequency readout

CTRL+RIGHT arrow or left arrow moves the frequency up or down 0.1KHZ
Note: if you hold down the ctrl key and the right or left arrow keys, you can tune up or down the band.

CTRL+UP ARROW or DOWN ARROW moves the frequency up or down 1.0KHZ
Note: this command does not work with the JAWS screen reader unless you first press the insert-3 key combination and then, hit ctrl up arrow or down arrow. If you press insert-3 and then, hold down the ctrl up or down arrow, you will be able to tune up or down the band in 1 KHZ increments.

ALT-SHIFT-M Read mode
Note: Often this command will stick when you get to the end of the selections and not move; in which case, you need to hit ctrl-m twice in quick secession, and then, you can cycle through the selections again.

ALT-Shift-B reads the button control settings

ALT-Shift-D reads the dropdown settings

ALT-Shift-S reads the slider controls

Special Note: while these latter keyboard commands allow you to read the buttons, dropdown and slider settings, at this time there does not appear any way of actually changing any of these setting with keyboard shortcuts. It is hoped that the RCForb client software will be more accessible with future versions of the software.

Once you feel reasonably comfortable with these basic keyboard commands, you need to click on the Remotehams icon on your desktop and start the Remotehams’ client. Next, you will need to turn on the text-to-speech function by hitting the key combination alt-o, which opens the options menu. Then, arrow down to the text-to-speech selection and click on it. The first thing you will see is the text-to-speech option which needs to be enabled. If it is already checked, you can just exit out of the option menu; if it is not checked as enabled, you need to check it to turn the text-to-speech on.

Finding Remote Stations, Listening and Tuning

It is strongly recommended you invest some time just listening and tuning stations using the Remotehams client software before you try transmitting. Besides, you need permission from each station owner in order to be able to transmit on a station using the Remotehams software client. This will be covered in more detail in the next section of this user’s Manual.

To find stations to access and be able to listen to just for practice, open the Remotehams software client by hitting enter on its icon on your desktop. When the program opens, you will see a vertical list of stations, one per line. They seem to be in alphabetical order by country. If you go to the very bottom of this list, or to the bottom of your screen, you will find stations in the United States. By arrowing up line-by-line, you will see different stations that you can click on to listen to. If you click on their calls, you will hear their transceivers, and an “OK” will pop up on your screen. Click on the OK, and you are ready to tune around by using the keyboard commands given above. Remember, to check to see if someone else is already using the station, and if they are always ask if you can tune before changing the frequency. If you are the only one shown to be using the transceiver, then, you are free to tune around, switch bands, modes, etc.

Alternatively, if you are interested in finding Remotehams in your specific country or state or surrounding states, you can go to the Remotehams website, then, to the Online Remotes link and click on it. That will take you to the Online Remotes page where you can sort the database by location, remote name, or radio type. If, for an example, you want to find all stations available in the state of Michigan, you can sort by location, and then, use your screen reader’s find command to find all of the stations listed in Michigan. They are listed by their state abbreviation; thus, Michigan would be listed as MI, and it is immediately followed with a comma; so, you would search for MI, putting a space before the MI and a comma immediately after it. Don’t be surprised if you find only one or two stations listed for your state. Hopefully, more will start using the Remotehams software in the future. Once you find a station that is available, you can just click on the call letters to begin listening to it following the user’s Manual instructions and keyboard commands given above. Alternatively, you can copy the call of the station, then, go to the RCForb client, click on the files menu, arrow down to “new Connection,” hit enter, and tab down to “nickname:” and type in the call of the station you want to go to. If there is already a station call in that edit box, you will need to delete it and type in the new station you want to go to. You can either just hit your return or enter key or tab down to “connect,” and hit return on it. Once you have gone to a station it is included automatically in your “Recent connections” list, which you get to by opening the files menu with alt-f, and it will be the first selection.

Transmitting Using the Remotehams Client Software

Once you are comfortable with the basic keyboard commands, logging onto different Remotehams stations, tuning around, changing frequencies, bands, modes, etc., you are ready to tackle transmitting using the Remotehams client. This is very simple, with one very slight exception, and that exception is that you must upload a copy of your ham license to the Remotehams’ website. The good thing is that you only need to do this one time. It is really easy to do. You need to get a digital version of your amateur radio license. If you don’t already have one, you can scan in an image of your license and save it as a .JPEG file. It says on the Remotehams website that you can upload a copy of your license in any one of several different formats: BMP, GIF, JPG, PDF, PNG, or TIFF. It must be noted that some people have encountered difficulty getting the PDF copies of their ham license to upload to the Remotehams website. However, no one has expressed any problems getting Remotehams to accept JPG versions.

You can upload a copy of your license to the Remotehams website from the website or from the Remotehams RCForbs software client. Just click on where it says something like “upload amateur radio license.”

Select browse, and then, find the digital copy of your license in whatever folder you saved it on your computer’s hard drive and click it; and then, press the send file button. When received, you should see an announcement letting you know it was successfully uploaded. If, for some reason, your license has not been successfully uploaded, when you go to your remotehams account, it will tell you something like: license not uploaded. However, if you have successfully uploaded a copy of your license, it will say:

Manage Your License

License image
(Click Image to Enlarge)

An image of your uploaded license will be displayed. Only the significant words are given here to let you know what you should hear.

OK, you are registered; you’ve accessed a few stations and familiarized yourself with the basic keyboard commands, and you have successfully uploaded a copy of your ham license. Now, you are ready to make some contacts.

The next hurdle you need to get over is obtaining permission from the stations’ owners allowing you to use their transceivers for transmitting. This is accomplished by accessing a station you want to transmit on, and hitting the keyboard command: ctrl-t. This is the command to toggle the transmit function on and off. The first time you do this, you will see an OK on the screen, but if you tab once, you will see the: request permission button. Click on this button to request permission to transmit using this transceiver. It may take you a few days to obtain permission, and sometimes, permission is not granted. Several of the stations are club owned, and you have to be a member of the club to use it. If it is an individual’s station, it is suggested that in addition to requesting permission using the RCForb client, you also look the individual up in the QRZ database to find his/her email address and write them a short note introducing yourself and requesting permission to use his/her station. Often this will get you a quicker response, and it also increases your likelihood of gaining his/her consent to use the station. Often the only way you know you have permission to use a station is by logging on and looking at your callsign; if there is an X next to your call, you have permission; if not, then, you don’t.

Once you obtain permission to use a station, you need to log onto it. Make sure you are OK to use it, and tune around to find someone calling CQ, or a net you can check into, or a QSO that you would like to join or find a clear spot on the band that you are allowed to use given your class of license, and call CQ yourself. Whatever you do, to transmit, you use the keyboard command: ctrl-t. This command toggles the transmit on and off. There is a very slight lag between the instant you hit ctrl-t and begin actually transmitting. This slight lag is especially noticeable when you toggle the transmit off. In some instances, you might even miss the first word or two of the person you are talking to.

Special Note: Handihams currently has one of its stations set-up for Remotehams access; it is W0ZSW. Soon, WA0EQO should also be accessible using the Remotehams RCForb client. Since these stations are not checked everyday by their custodians, you should contact the Handihams’ office to request permission to use these stations. Thus, you need to access these stations using the RCForb client on your computer and request access, but in addition, you should also contact the Handihams’ office either by email or a phone call requesting access. As suggested above, this is a good procedure to follow when requesting full access to any of the stations, not just Handihams.

Are you a CW operator? You can use Remotehams on CW too. Not all stations are set-up for the CW mode of operation, but some are. You can type what you are sending on your computer’s keyboard, and it is resent out by the Remote station’s keying software. You need to look for those remote stations that indicate they are CW capable and seek access to those stations as described earlier in this manual.

It is a little tricky to get into. First, you need to change the mode to CW by using the keyboard command CTRL-M. Next, you need to use the keyboard shortcut to get into the “Window Screen.” You do this by hitting your tab key two or three times and then, use the key combination of ALT-W. If the Window screen does not pop open, try tabbing a couple of more times and hit ALT-W again. Once this Window Screen opens, you need to arrow down to “CW Keying” and hit enter. Now, you need to tab once or twice again and hit ALT-W a second time and, once again, arrow down to “CW Keying” and hit enter. Now, you should be where you need to be to begin operating CW. If you type in your call, for example, you should hear it coming back through the monitor in CW. You can type as fast as you want. The code will be sent only as fast as the CW is set for, e.g. 15 wpm, 20 wpm, etc. At the time of this writing, no method has been found for being able to adjust the keying speed when using a screen reader.

Reserving Time Slots

If you donate to the RemoteHams developers, you can reserve 30 minute time slots when only you and the administrator can tune the radio. When in the RCForb client, the keyboard command ALT-R will place you in the reserve time slots area where you can donate to the RemoteHams developers. If you decide to contribute financially, you will be rewarded one (1) 30 minute Reserved Slot for each dollar ($1 USD) contributed.
Reserved Slots may be used on a remote to prevent another user from “tuning” the remote for a 30 minute session. This can be very useful in reserving a remote for a Net, contest, working a dx contact or just to prevent any unwanted interference with remote operation. All other users connected to the remote will have RX only permission during this time. This does not override administrators, they always have control of the remote for security reasons and are visible with an (A) in the remote’s user list.
(You will be rewarded Reserved Slots instantly when contributing through PayPal.)

A Final Word of Caution

Most of the blind hams that are using the Remotehams RCForb client have reported discovering many inconsistencies in the way the client looks with their screen readers and the way the various commands work or don’t work. Some of these inconsistencies seem to come from the fact that the station owners can select different skins which greatly affect how the rig appears on the computer screen. Thus, in like manner, this also greatly affects how the controls are arranged and what you see with your screen reading program. The other explanation for some of the inconsistencies is the fact that many different makes and models of ham transceivers are being used, and it is extremely difficult for one software client to work exactly the same across all of these different platforms and pieces of equipment.

The key point, however, is that we are fortunate to have this kind of technology available to us, and for the most part, it is pretty accessible, not perfect certainly, but definitely useable.

73,
Ron, K8HSY
Dr. Ronald E. Milliman, retired Professor of Marketing

HARA Arena to Close – Hamvention® to find new home

On behalf of the Hamvention General Chair and the DARA Board of Directors. This is an Official Announcement concerning the 2017 Dayton Hamvention and beyond.

Dayton Hamvention® 2017 News Update

The Dayton Amateur Radio Association (DARA) regrets to inform our many vendors, visitors and stakeholders that, unfortunately, HARA has announced the closing of their facility. We have begun execution of our contingency plan to move Hamvention® 2017 to a new home.
DARA and Hamvention® have enjoyed many successful years working together with HARA Arena and we wish the Wampler family the best.
DARA and Hamvention® have been working on a contingency plan in the event HARA would become unavailable. We have spent many hours over the last few years evaluating possible locations and have found one in the area we believe will be a great new home! Due to logistics and timing issues, we will make a formal announcement introducing our new partner. This information will be coming soon. We all believe this new venue will be a spectacular place to hold our beloved event. Please rest assured we will have the event on the same weekend and, since it will be in the region, the current accommodations and outside events already planned for Hamvention® 2017 should not be affected.
We look forward to your continued support as we move to a new future with The Dayton Hamvention®.

Ron Cramer
General Chairman
Dayton Hamvention® 2017

Extra Class Pool goes into effect 1 July 2016

Studying for your Extra Class ticket?  It’s time to switch gears and start using the latest question pool, which is the Public Release March 5, 2016.  This pool goes into effect for all VE testing on the first day of July 2016.

You can always find the latest version of any question pool on the NCVEC website at http://www.ncvec.org/.

If you are blind and wish to use the recorded version with only the correct answers as a study guide, you will be able to find the latest version read by Handiham volunteer Jim Perry, KJ3P, on the Handiham website in the members section by July 1.  It will also be available in DAISY format for download as a zip file and for placement on NLS digital cartridges.

A great big THANK YOU to Jim for his excellent recording!

Accessibility Improved at W0EQO

Users connecting to W0EQO will now hear the receiver audio immediately instead having to find and toggle the power button on the graphical user interface. While there are keystroke commands for the basic functions used in operation of the RCForb software, there is no such command for the radio’s power switch. That meant that JAWS users had to use a tedious process of trying to find the button labeled PWR with the JAWS cursor.

Now when you connect the radio is already running.
